Perforated Metal Mesh

Feature

• Ventilation, light and air penetration and anti-sand property.
• High strength and security.
• Perfect anti-corrosion property and rust resistance.
• Various choices in opening sizes/areas, gauges and materials, hole shapes/patterns.
• Aesthetic appearance.
• Low maintenance.

Normal Hole Patterns

As to the unique hole type, our technical team can make CAD drawing for you according to your sample or description. If you have a CAD drawing, please directly send to us.

Specification

• Material: Plain steel, mild carbon steel, aluminum, stainless steel (302, 304, 304L, 316, 316L), brass, copper.
• Surface treatment: Galvanized, PE/PVC coated and powder coating.
• Thickness: 0.2–25 mm.
• Width by length: 1000 × 2000 mm to 2000 × 6000 mm or according to customer's requirements.
• Standard sizes: 1000 × 2000 mm, 1000 × 2400 mm and 1200 × 2400 mm.
• Hole patterns: Round hole, square hole, slotted hole, hexagonal hole and decorative hole.
• Hole diameter: 0.2–100 mm.
• Packing
  • Coiled plate: in water-proof plastic bags then in wood pallets.
  • Flat plate: in plastic film then in wood pallets.

Application

Perforated metal is used in commercial, industrial and domestic sites, it's vital for the following applications:

• Screens.
• Diffusers.
• Balustrades.
• Filter.
• Vent.
• Signage.
• Partitions.
• Enclosures.
• Noise barriers.
• Protective fences.
• Sunshade.
• Decoration.
• Perforated metal building facade.
• Perimeter protection screen.
